Features
MIN-2-MAX BURNERS®
With the widest range of BTU performance in the industry, these best-in-class dual-flame sealed burners offer unrivaled versatility — from a roaring 18,000-BTU boil to a gentle 450-BTU simmer.
CUSTOMCONVECT3™ CONVECTION TECHNOLOGY
Distributes heat evenly throughout the oven by adding a third cooking element plus a variable speed fan.
SMOOTH-GLIDE® OVEN RACKS
Ball bearing oven racks glide with unparalled ease and extend fully for effortless access.
Additional Features
EXTRA LARGE OVEN CAPACITY
Spacious 6.4 cubic foot interior gives you all the cooking space you need.
Specifications
General
Fuel Type
Dual Fuel - Natural Gas
Installation Type
Freestanding
Color
Stainless Steel
Manufacturer Color
Stainless Steel
Cooktop
Burners/Elements
6
Burners/Elements Output
• Center Front: 14000 BTU
• Center Rear: 9500 BTU
• Left Front: 450 - 18000 BTU (Dual Flame)
• Left Rear: 14000 BTU
• Right Front: 450 - 18000 BTU (Dual Flame)
• Right Rear: 850 - 5000 BTU
• Center Rear: 9500 BTU
• Left Front: 450 - 18000 BTU (Dual Flame)
• Left Rear: 14000 BTU
• Right Front: 450 - 18000 BTU (Dual Flame)
• Right Rear: 850 - 5000 BTU
Burners
Sealed
Other
Griddle,Wok
Oven
Capacity (cu. ft.)
6.4 cu.ft.
Number of Ovens
Single
Programs
• Bake
• Broil
• Convection Bake
• Convection Roast
• Broil
• Convection Bake
• Convection Roast
Features
Technologies
• Smooth-Glide® Oven Racks
• Min-2-Max Burners®
• CustomConvect3™ Convection Technology
• Min-2-Max Burners®
• CustomConvect3™ Convection Technology
Convection
Yes
Oven Light
Yes
Self-Cleaning
Yes
Additional Information
• Manual-Select Fan Convection Cooking Mode
• Bake Burner (BTU): 1 (34,000)
• Broil Burner (BTU): 1 (14,000)
• Convection Burner (Watts): 350
• Rack Configuration: 3 HD Handle (glide) 1 Handle (fixed)
• Knob Type: Plastic weighted skirted Knobs with Bezel
• 3 Continuous Grates
• Bake Burner (BTU): 1 (34,000)
• Broil Burner (BTU): 1 (14,000)
• Convection Burner (Watts): 350
• Rack Configuration: 3 HD Handle (glide) 1 Handle (fixed)
• Knob Type: Plastic weighted skirted Knobs with Bezel
• 3 Continuous Grates
Accessories
Included
• Griddle
• Simmer Plate
• Stainless Steel Cleaner
• Wok Ring
• Simmer Plate
• Stainless Steel Cleaner
• Wok Ring
Optional
• 9" Stainless Steel Backsplash – PN# 903134-9100
• 4" Stainless Steel Kickplate – PN# 318352652
• Black Knobs Kit – PN# 903108-9020
• 4" Stainless Steel Kickplate – PN# 318352652
• Black Knobs Kit – PN# 903108-9020
Dimensions
Class Width
36"
Width
35.87 inch(es) / 91.1 cm
Height
41.61 inch(es) / 105.7 cm
Depth (Without Handles)
10.83 inch(es) / 27.5 cm
Shipping Dimensions
Weight
404 lb(s) / 183.25 kg
Warranty
Warranty
Limited 1 Year Parts and Labor
