Features
CUSTOMCONVECT3™ CONVECTION TECHNOLOGY
Distributes heat evenly throughout the oven by adding a third cooking element plus a variable speed fan.
MIN-2-MAX BURNERS®
With the widest range of BTU performance in the industry, these best-in-class dual-flame sealed burners offer unrivaled versatility — from a roaring 18,000-BTU boil to a gentle 450-BTU simmer.
SMOOTH-GLIDE® OVEN RACKS
Ball bearing oven racks glide with unparalled ease and extend fully for effortless access.
Specifications
General
Fuel Type
Natural Gas
Installation Type
Freestanding
Color
Stainless Steel
Manufacturer Color
Stainless Steel
Cooktop
Burners/Elements
6
Burners/Elements Output
• Center Front: 14000 BTU
• Center Rear: 9500 BTU
• Left Front: 750 - 18000 BTU (Dual Flame)
• Left Rear: 14000 BTU
• Right Front: 750 - 18000 BTU (Dual Flame)
• Right Rear: 850 - 5000 BTU
• Center Rear: 9500 BTU
• Left Front: 750 - 18000 BTU (Dual Flame)
• Left Rear: 14000 BTU
• Right Front: 750 - 18000 BTU (Dual Flame)
• Right Rear: 850 - 5000 BTU
Burners
Sealed
Other
Wok
Oven
Capacity (cu. ft.)
6.0 cu.ft.
Number of Ovens
Single
Programs
• Bake
• Broil
• Convection Bake
• Convection Roast
• Self-Clean
• Preheat: Integrated with Bake
• Broil
• Convection Bake
• Convection Roast
• Self-Clean
• Preheat: Integrated with Bake
Features
Technologies
• Smooth-Glide® Oven Racks
• Min-2-Max Burners®
• CustomConvect³™ Convection Technology
• Min-2-Max Burners®
• CustomConvect³™ Convection Technology
Convection
Yes
Downdraft Ventilation
No
Oven Light
Yes
Self-Cleaning
Yes
Wi-Fi
No
Additional Information
• Bake: 30000 BTU
• Broil: 11500 BTU
• Convection System: True 350 Watt Single Fan
• Rack Configuration: 2 Glide 1 Handle
• Extra-Large Oven Window
• Rack Positions: 13 Positions
• Interior Color: Cobalt Blue
• Broil: 11500 BTU
• Convection System: True 350 Watt Single Fan
• Rack Configuration: 2 Glide 1 Handle
• Extra-Large Oven Window
• Rack Positions: 13 Positions
• Interior Color: Cobalt Blue
Electrical Information
Information
• 120 V
• 60 Hz
• 7 A
• 60 Hz
• 7 A
Accessories
Included
• LP Conversion Kit
• Stainless Steel Cleaner
• Wok Ring
• Stainless Steel Cleaner
• Wok Ring
Dimensions
Class Width
36"
Width
35.87 inch(es) / 91.1 cm
Height
41.61 inch(es) / 105.7 cm
Depth (Without Handles)
27.5 inch(es) / 69.85 cm
Weight
380.01 lb(s) / 172.37 kg
Additional Dimensions
• Interior Depth: 19-5/8"
• Interior Width: 30-1/8"
• Interior Height: 17-5/8"
• Interior Width: 30-1/8"
• Interior Height: 17-5/8"
Shipping Dimensions
Weight
425.01 lb(s) / 192.78 kg
Warranty
Warranty
1 Year
UPC
UPC#
012505804830
